Gears: lifting mechanism for monitor Stream Master II (3480-3482 with handwheel)
Detailed contents :
|
Part no |
Ref. MMF |
Designation |
Quantity included |
|
44 |
- |
PLANETARY GEAR RING |
1 |
|
52 |
- |
SHOULDER SLEEVE |
8 |
|
53 |
- |
HEXAGONAL SOCKET HEAD CAP SCREW WITH SHOULDER |
8 |
|
90 |
- |
AXIS OF ROTATION |
1 |
|
91 |
- |
PLANETARY GEAR |
8 |
|
92 |
- |
DRIVE SUPPORT |
1 |
|
93 |
- |
SHOULDERED SPACER |
1 |
To access the individual parts, please refer to the interactive table in the 'KIT CONTENTS' tab ('Find out more' button below)
BRONZE BALL FOR ROLLER 109342 3/8" (pack of 50)
Pack of 50 bronze balls for 109342 3/8" AKRON bearings.
O-RING 757210 2-241
Nitrile rubber O-ring for AKRON mechanisms 757210 N70 2-241.
O-RING 757326 2-158
Nitrile rubber O-ring for AKRON mechanisms 757326 N70 2-158.
TEFLON BEARING SEAL 803058 4.835
Teflon bearing seal for AKRON mechanisms 803058 UHMW 4.835 ID.
O-RING 757020 2-120
Nitrile rubber O-ring for AKRON N70 2-120 mechanisms.
O-RING 757319 2-343
Nitrile rubber O-ring for AKRON N70 2-343 mechanisms.
Maintenance/repair kit - monitor Stream Master II (3480-3482)
Detailed contents :
|
Part no |
Ref. MMF |
Designation |
Quantity included |
|
10 |
40590 |
O-RING 2-343 |
1 |
|
11 |
32802 |
O-RING SEAL 2-241 |
1 |
|
12 |
40591 |
O-RING SEAL 2-158 |
1 |
|
13 |
33270 |
BALLS FOR 3/8" BEARING |
75 |
|
14 |
33798 |
FULL SCREW CAP |
2 |
|
15 |
33806 |
PIERCED SCREW CAP |
2 |
|
27 |
34881 |
O-RING 2-029 |
2 |
|
77 |
40340 |
TEFLON BEARING SEAL 4.835 |
1 |
|
78 |
40341 |
TEFLON BEARING SEAL 4.185 |
1 |
|
79 |
40342 |
O-RING SEAL 2-242 |
1 |
|
80 |
33800 |
O-RING SEAL 2-246 |
1 |
|
81 |
33802 |
O-RING 2-347 |
1 |
|
82 |
- |
O-RING 2-348 |
1 |
To access the individual parts, please refer to the interactive table in the 'KIT CONTENTS' tab ('Find out more' button below)
