Drive mechanism with belt for elevation system - monitor Stream Master II (3480-3482)
Detailed contents :
Part no |
Ref. MMF |
Designation |
Quantity included |
55 |
- |
TEFLON SHOULDERED SPACER |
2 |
88 |
39151 |
O-RING SEAL 2-154 |
8 |
94 |
- |
Notched pulley axle |
4 |
95 |
- |
pOULIE wheel |
2 |
96 |
- |
BELT |
2 |
To access the individual parts, please refer to the interactive table in the 'KIT CONTENTS' tab ('Find out more' button below)
O-RING 757446 2-347
Nitrile rubber O-ring for AKRON mechanisms 757446 N70 2-347.
NEEDLE BEARING 704941 3/8ID B-67
Needle roller bearing for AKRON mechanisms 704941 3/8ID B-67.
SHAFT FOR ROTATION MECHANISM 769525 303-304
Rotating axle for AKRON mechanisms 769525 303-304.
Gears: rotation mechanism for monitor Stream Master II (3480-3482)
Detailed contents :
Part no |
Ref. MMF |
Designation |
Quantity included |
46 |
- |
AXIS OF ROTATION |
1 |
47 |
- |
TEFLON WORM SCREW |
1 |
48 |
34521 |
SPRING PIN |
1 |
51 |
39138 |
7:1 PLANETARY GEAR |
1 |
52 |
- |
SHOULDER SLEEVE |
4 |
53 |
- |
HEXAGONAL SOCKET HEAD CAP SCREW WITH SHOULDER |
3 |
54 |
- |
PLANETARY GEAR RING |
1 |
55 |
- |
TEFLON SHOULDER SPACER |
1 |
To access the individual parts, please refer to the interactive table in the 'KIT CONTENTS' tab ('Find out more' button below)
O-RING 757326 2-158
Nitrile rubber O-ring for AKRON mechanisms 757326 N70 2-158.
NEEDLE BEARING 704437 3/8ID NTA613
Needle bearing for AKRON 704437 3/8ID NTA613 mechanisms.
Elevating mechanism - monitor Stream Master II (3480-3482)
Detailed contents :
Part no |
Ref. MMF |
Designation |
Quantity included |
36 |
34397 |
spring washer |
2 |
37 |
32804 |
thrust washer |
8 |
38 |
33649 |
stop With needles |
4 |
39 |
34478 |
half-moon key |
2 |
40 |
34839 |
hardened steel worm screw |
2 |
42 |
- |
hexagon socket head cap screw |
8 |
49 |
- |
shutter |
2 |
50 |
- |
teflon-shouldered spacer |
2 |
58 |
34279 |
O-RING 2-112 |
2 |
To access the individual parts, please refer to the interactive table in the 'KIT CONTENTS' tab ('Find out more' button below)
